Glue for top cover of washing machine

model	Applicable temperature	Melt viscosity @130℃	Remark
PUR	10~25℃	4500~6500	Longer whitening
	20~41℃	4000~6000	Short whitening time, suitable for summer and South China
	10~30℃	4000~6000	The whitening time is moderate, applicable in spring and autumn and winter, and it can be used in summer
	20~35℃	4000~8000	UV resistance

Temperature setting of platen press

Press the plate	Hose	Glue gun
130-150℃	130-145℃	120-145℃

Technical requirements for top cover plate of washing machine

Common substrates: ABS, melamine board, ink glass fast positioning,

Hard requirements

excellent high and low temperature performance
without flashing , high waterproofing
and high final strength ,
good colloid strength and thermal stability

Operational requirements

after curing , otherwise the wire drawing will affect the production
of stable glue, no bubbles, continuous glue
odor will greatly affect the comfort of workers.
When the track is short, air conditioning or fan should be installed in the workshop to speed up whitening

Main performance indicators of glue for top cover of washing machine

project	index	project	index
Appearance	White solid	Shear strength/MPa@25℃	≥3.5
Density (g/cm3)	1. 10±0.1	Bonding strength	Cover sheet break
Elongation of break	≥400%	Adhesion strength after high and low temperature cycle	Cover sheet break

Note:
1. The shear force test substrate is ABS* melamine plate, with an adhesive area of 12.5mm*25mm, and a glue layer thickness of 0.3~0.6mm.
2. High and low temperature cycles for 15h*70℃*RH50%, 2h*23℃, 3h*-30℃*RH50%, 2h*23℃. There are 6 cycles in total.
