Electronic glue technical requirements

Common substrates: ABS, PC, PC + 2 0 GF, glass, aluminum, stainless steel, etc.

Hard requirements
  • The final strength is high
  • and low temperature resistance, good weather resistance , hardness
  • meets

Operational requirements

  • the corresponding product requirements
  • and operating requirements. Good
  • thermal stability is good, no wire
  • drawing storage stability, less crust, no shell removal

Electronic glue related introduction

project PUR
Working hours min 3-5 2-4 2-4 2-4 4-6 4-6 20
color Ivory white Ivory white Ivory white Ivory white black Ivory white Ivory white
Melt viscosity @110℃ cps 3300-4500 3000-5000 2000-3000 5000-7500 2500-4000 4000-5500 3000-4500
use Universal, long
working hours		 Universal, medium
viscosity		 Universal type, small needle or narrow frame,
high metal bonding		 Universal type, high initial strength, fast strength increase Black shading,
OD > 4.0		 Long opening time, can
be removed at 85℃		 Long opening time, high final
intensity
Viscosity stability -
Melt viscosity/110℃
after 5 hours of place
@110℃ cps		 3700/5900 4000/4600 2200/2600 6500/7000 3000/3500 4500/5000 3000/3500
Initial strength
Shear strength in 1 minute		 0.046 0.25 0.165 0.64 0.07 0.023 0.11
5 minutes
shear strength		 0.62 0.70 0.17 0.92 0.12 0.13 0.34
Shear in 30 minutes
strength 		0.89 0.96 0.37 1.7 0.46 0.42 0.75

project PUR
Final strength - shear force ABS- ABS 9.77 8.15 10.53 9.65 6.23 6.43 5.68
PC-PC 9.43 6.83 7.73 9.2 9.57 7.32 14.99
PC-anode aluminum 11.46 6.23 8.29 11.7 6.68 6.75 10.8
PC-Stainless Steel 10.62 8.29 7.72 11.01 7.82 6.12 11.2
Final strength - pulling force ABS- ABS 1.79 1.68 1.7 1.52 1.44 1.34 3.34
PC-PC 3.62 3.44 3.8 3.22 3.15 2.95 5.12
PC-anode aluminum 3.7 3.23 3.14 3.77 1.54 1.89 3.81
PC-Stainless Steel 4.44 3.56 3.07 4.02 1.98 1.35 3.11

  • Product Features Summary
    1. The opening time is long, and the glue dispensing on the metal has a suitable operating time, and the strength is very high. It is used to decorate the metal sheet on the side of the mobile phone. Test method: 1.2m drum * 300 flip, 8830 flip 280 times. Applied to bond the side frame of the mobile phone and bond the battery cover of the mobile phone.

    2. The metal or plastic middle frame is bonded to the front screen. Suitable for small needle narrow bezels, camera decorative parts, no wire drawing. Suitable for spraying glue. Keep pressure for 30-50 minutes. Good thermal stability, with a viscosity increase of less than 20% at 120 degrees for 6 hours.

    3. The initial strength is high, and the strength can reach 60% in two hours, and the final strength is high.
    Can be applied to bonding of mobile phone TP screen. Suitable for bonding of plastics and metals with deformation, the glue force within 1-2 hours can resist the deformation force of the substrate.

    4. The opening time is moderate, the glue line is smooth, the light-shading effect is good, the OD value is about 4.5, and the bonding strength is high. You can use 26-28-digit needle dispensing, and after dispensing, you can test the light shading, without shrinking or collapse. It can be used continuously for 8 hours, suitable for camera round hole dispensing.

    5. Long opening time, the final intensity is high. Suitable for larger workpieces with complex dispensing paths.
